Bunded Chemical Tank 21,000ltr
Bunded Chemical Tank 21,000ltr
A 21,000ltr Polymaster Double-Walled Self-Bunded is literally a tank-within a tank. This means we manufacture a smaller tank (to hold the bulk chemicals securely), inside another purpose-built polyethylene tank. The ‘outer tank’ has 110% capacity of the internal tank. So, in the unlikely event of a leak occurring it will prevent the chemicals coming into contact with the environment and your employees.
Polymaster Chemical Self Bunded Tanks have the ability to store over 1,965 chemicals. Check out our Chemical Compatibility Chart.
Code | Capacity | Diameter | Height | Material | SG Rating | Cabinet | Sealed | Warranty | Datasheet | Drawings | CADs |
---|---|---|---|---|---|---|---|---|---|---|---|
BPST21000LGY-1.5 | 21,000 Ltrs | 3570mm | 3515mm | Hexene PE | 1.5 | Single Door / Double Door | No | 5 Years | Datasheet | Drawing | STEP |
BPST21000LGY-1.75 | 21,000 Ltrs | 3570mm | 3515mm | Hexene PE | 1.75 | Single Door / Double Door | No | 5 Years | Datasheet | Drawing | STEP |
BPST21000LGY-2 | 21,000 Ltrs | 3570mm | 3515mm | Hexene PE | 2 | Single Door / Double Door | No | 5 Years | Datasheet | Drawing | STEP |
BPST21000LGY-CG-1.5 | 21,000 Ltrs | 3570mm | 3515mm | Chemical Grade PE | 1.5 | Single Door / Double Door | No | 5 Years | Datasheet | Drawing | STEP |
BPST21000LGY-CG-1.5 | 21,000 Ltrs | 3570mm | 3515mm | Chemical Grade PE | 1.5 | Single Door / Double Door | Yes | 5 Years | Datasheet | Drawing | STEP |
BPST21000LGY-CG-1.75 | 21,000 Ltrs | 3570mm | 3515mm | Chemical Grade PE | 1.75 | Single Door / Double Door | No | 5 Years | Datasheet | Drawing | STEP |
BPST21000LGY-CG-1.75 | 21,000 Ltrs | 3570mm | 3515mm | Chemical Grade PE | 1.75 | Single Door / Double Door | Yes | 5 Years | Datasheet | Drawing | STEP |
BPST21000LGY-CG-2 | 21,000 Ltrs | 3570mm | 3515mm | Chemical Grade PE | 2 | Single Door / Double Door | No | 5 Years | Datasheet | Drawing | STEP |
BPST21000LGY-CG-2 | 21,000 Ltrs | 3570mm | 3515mm | Chemical Grade PE | 2 | Single Door / Double Door | Yes | 5 Years | Datasheet | Drawing | STEP |
- Level transmitter mount
- Weather proof vent
- Inspection hatches
- Mechanical level indicator
- Bolt down lugs
- Outer tank exceeds 110% capacity of storage tank
- Bund alarm float switch
- Bund drain
- Outlet sealed to inner and outer tank
- Lifting lugs
- High level alarm float switch
- Bund alarm & high level alarm on exterior of tank
- Top fill assembly with camlock and drain
- Tank outlet and valve
- 25 Year design life
Optional cabinets can be added for segregation of equipment, increased capacity for housing multiple dosing systems and protection for equipment.
Join multiple tanks together with double containment (bunded) connections for unlimited capacity.
Add a Chemical Unloading Panel with single and 3-phase options, all in one Tank Management System or Tank Overfill Protection (including alarm, inloading high level safety cut-off and Radar & Ultrasonic Level Transmitters available).
