Home Chemical and Water Treatment Cone Bottom

Cone Bottom Tanks

Polymaster Cone bottom tanks suit many applications including soil remediation, chemical mixing and sludge clarification processes.  All tanks are one-piece construction with no seams or joins. Either 1SG or 1.5SG tanks are available, ranging from 600ltrs to 30,000ltrs.

Get A Quote
Home Chemical and Water Treatment Cone Bottom

Heavy Duty – Application Specific

Polymaster Cone Bottom are built to last to suit a wide range of applications.  The steep 50° Cone design reduces the chance for a viscous liquid to build up inside the tank, allowing for easier drainage and take-off.

Image Capacity Diameter Height SG Available Cone Angle
600 Ltrs 1165 x 1165mm 1410mm 2 50 ° View Product Options
1,000 Ltrs 1165 x 1165mm 1790mm 2 50 ° View Product Options
1,500 Ltrs 1165 x 1165mm 2145mm 2 50 ° View Product Options
2,000 Ltrs 1165 x 1165mm 2570mm 2 50 ° View Product Options
5,000 Ltrs 2380mm 3020mm 1 / 1.5 50 ° View Product Options
7,500 Ltrs 2380mm 3620mm 1 / 1.5 50 ° View Product Options
10,000 Ltrs 2380mm 4210mm 1 / 1.5 50 ° View Product Options
12,500 Ltrs 2380mm 4800mm 1 / 1.5 50 ° View Product Options
20,000 Ltrs 3450mm 4268mm 1 / 1.5 50 ° View Product Options
25,000 Ltrs 3450mm 4815mm 1 / 1.5 50 ° View Product Options
30,000 Ltrs 3450mm 5363mm 1 / 1.5 50 ° View Product Options

Contact Polymaster today about your liquid storage requirements

Enquire about product Call our team on 1800 062 064

Unmatched chemical compatibility

We understand chemicals, which is why we undertake a chemical compatibility test to ensure our specially formulated PE material will safely contain a massive range of chemicals in the market place including:

  • Sulfuric Acid (98%)
  • Ferris Chloride
  • Ferric Chloride
  • Nitric Acid
  • Alum
  • Sodium Metabisulfite
  • Sodium Hypochlorite
  • Sodium Hydroxide
  • Hydrochloric Acid
  • Magnesium Hydroxide
Download Brochure

We understand chemical tank requirements

Chemical storage solutions are usually all about compliance, standards, regulations and OHS issues due to the risk associated with storing volumes of chemical. A PE Chemical Tank is an important technical decision to make and therefore choosing the right company to work with is extremely critical.

Focus on making the right choice for your specified chemicals and ensure the supplier is;

  1. certified to AS4766:2006 Polyethylene Storage Tanks for Water and Chemicals.
  2. understand the technical requirements for chemical storage
  3. has the resources available and specialist engineers experienced in PE materials.

Carefully invest in a chemical storage option that is fit for purpose, has the right design life and efficient maintenance schedule taken into consideration.

About Polymaster

Liquid Storage Solutions

When you have a complex problem you need a custom solution. Our team of engineers take the time to understand your needs and develop unique solutions that don’t just solve the problem, but also give you long term benefits. Our tanks are already being extensively used across all industry sectors including;
View All Solutions
Transport
Water Utilities
Chemical Manufacturers
Mining
Food & Beverage

Highest Quality & Standards

Food Grade

Food-grade polyethylene, certified to AS/NZS4020, the Australian standard for drinking water

Quality Assurance

Polymaster is certified for the international standard for quality management ISO9001

Product Certification

Standard AS/NZS 4766:2006 for peace of mind. Licence no. BMP657671 & BMP650824

Trusted by Australian businesses

At Polymaster our design and engineering team are encouraged by your imagination and we make dreams become a reality. Our latest projects for the petrochemical, mining, oil and energy, municipal water treatment plants and chemical industries can be found here.
View all Projects
NorthConnex
The NorthConnex project required conical mixing tanks for mixing concrete admixtures onsite.
Read More
FMG North Star Pilot Plant
A solution specially engineered from extra-heavy duty materials to withstand the high SG of the slurry content.
Read More
Hire Tanks
The flexibility to deploy these mobile systems and remove them when they are no longer required saves time...
Read More
Nambucca Shire
Polymaster designed a custom-made solution for Nambucca Shire providing a long-term chemical storage investment.
Read More
View all Projects

What Our Clients Say

“We’ve found working with Polymaster to be a positive experience. The quality of the products which we have used has been very high, and the willingness and technical capacity of the staff to tackle non-routine engineering modifications has given us confidence in the finished build.”
P. Baker
Land Energy Pty Ltd
"The decision to sell Polymaster tanks to my customers is an easy one due to the fact that I strongly believe they are the best quality tanks on the market and I can confidently stand by the product I am supplying."
David Hartwig
Plumbing Contractor
"We are very pleased with the choice we made to go with Polymaster due to the quality and excellent service. We will endeavour to use more Polymaster tanks as we continue to upgrade our property. "
Matthew
Bridgewater SA
