Round Process Tank 50,000 Ltr
Round Process Tank 50,000 Ltr
Proven Chemical Resistance – The 50,000ltr Round Process Tank has long been recognised for its resistance to aggressive media. LLDPE Tanks are suitable for the containment of most corrosives including chlorides, detergents, salts, and variable PH solutions.
Certified to Australian Standards – AS/NZS4766-2006 Polyethylene storage tanks for water and chemicals
Features
- Specific Gravities up to 1.5SG
- Operating temperatures from -20ºC to +40ºC.
- FEA Engineered Design with NO internal pole
- Custom Process Connections →600NB
- Multiple types of PE available
- Double Strength UV+ resin for ultimate protection against Australia’s harsh sun
- Australian Made
| Code | Capacity | Diameter | Height | Material | SG Rating | Sealed | Wall Profile | Warranty | Datasheet | Drawings | CADs |
|---|---|---|---|---|---|---|---|---|---|---|---|
| PST50KL | 50,000 Ltrs | 4600mm | 3440mm | 7060 HDPE Hexathene | 1 | No | Smooth | 5 Years | Datasheet | Drawing | STEP |
| PST50KL-1.5 | 50,000 Ltrs | 4600mm | 3440mm | 7060 HDPE Hexathene | 1.5 | No | Smooth | 5 Years | Datasheet | Drawing | STEP |
| PST50KL-CG-1.5 | 50,000 Ltrs | 4600mm | 3440mm | 7065 HDPE Chemical Grade | 1.5 | No | Smooth | 5 Years | Datasheet | Drawing | STEP |
| PST50KL-CG-1.5 | 50,000 Ltrs | 4600mm | 3440mm | 7065 HDPE Chemical Grade | 1.5 | Yes | Smooth | 5 Years | Datasheet | Drawing | STEP |
Our size range is extraordinarily large. Over 24 sizes to choose from ranging from 200L right through to 50KL.However, don’t limit yourself as each tank can be interconnected giving you unlimited storage capacity.
Standard Kits
- 50mm Top Fill Assembly with ball valve, camlock & drain
- 50mm BSP outlet with PVC ball valve
- 90PE Hook vent with mesh screen
- 90PE Overflow assembly
- Mechanical level indicator &
- 4 Bolt down lugs
Extra Resistance
Where added resistance is required, Polymaster Industrial tanks are available in Hexathene 7080. This special resin grade has a higher density and extra resistance to Diesel Fuel and other plasticiser chemicals.
